Meet FieldFab:
the expeditionary 3D printer designed for the world’s extreme environments.
Replace mission-critical parts in the field, reducing lead time and enabling materiel readiness.
Conforming to MIL-STD-810H, FieldFab has demonstrated consistent performance, even when subjected to:
Extreme cold (-40°C), extreme heat (50°C), and high altitude
Temperature and humidity cycling
Rain and condensation
Operational shock and vibration
Print advanced materials continuously, even during tactical transport on land, sea, or in air.
Our capabilities result from being embedded within USMC and Army units for over 3 years, codeveloping systems with warfighters.
As a part of a Cooperative Research and Development Agreement (CRADA) with USMC, NIWC Pacific, and US Army CCDC, FieldFab has been tested, refined, and deployed in over 29 field exercises alongside the Army, Navy, Marines, SOF, and Joint Forces.
Print advanced, high-temperature materials with a low training burden.
FieldFab is compatible with all polymer-based 3D printing filaments.
Direct Metal Replacements
Biocompatible Parts
Flexible Parts
Standard Parts
Coolant Coupler (ULTEM)
Naval Vessel Engine Gasket (TPU)
Locking Ring 3-Phase Connector (Nylon)
Ski Boot Lock (ULTEM)
Water Pump Impeller (Nylon CF)
MIL-SPEC Barrel Connector (Nylon)
Technical Specifications
3D PRINTING
| Nozzle Temperature | < 500°C (932°F) |
|---|---|
| Bed Temperature | < 200°C (392°F) |
| Chamber Temperature | < 80°C (176°F) |
| Print Volume | 280mm x 280mm x 280mm (11.02” x 11.02” x 11.02”) |
| Supported Materials | All standard polymer filaments and polymer- based composites (i.e. ULTEM, TPU, Nylon-CF, PETG, Nylon, PLA, etc.) |
MECHANICALS
| Housing | LMDP plastic exterior, aluminum print shell |
|---|---|
| Dimensions | 24” x 26” x 39” |
| Weight | 190 lbs |
ENVIRONMENTALS
| Temperature | Operational: 40°C* to 50°C (-40°F* to 122°F) * automatic system pre-heat enabled Storage: -40°C to 70°C (-40°F to 158°F) |
|---|---|
| Certifications | MIL-STD-810H, AS9100D/ISO9001, Made in USA |
INTERFACE / ELECTRONICS
| Digital Interface | GETAC F110 with design suite, digital data vault access |
|---|---|
| Power | 80V—264V, 47Hz—63Hz (AC outlet) |
| Power Consumption | 1.2kW peak, 10A Max |
